Heavy Duty Offset Sidebar Forged Chain with SGS Approved
    • Heavy Duty Offset Sidebar Forged Chain with SGS Approved
Introduction

Heavy Duty Offset Sidebar Roller Chain
The heavy duty offset sidebar roller chain is designed for drive and traction purposes, and is commonly used on mining equipment, grain processing equipment, as well as equipment sets in steel mills. It is processed with high strength, impact resistance, and wearing resistance, so as to ensure safety in heavy duty applications.
Design and Processing Advantages
1. Made of medium carbon steel, the offset sidebar roller chain undergoes processing steps like heating, bending, as well as cold pressing after annealing.
2. The pin hole is created by impact extrusion, which increases the inner surface smoothness for the hole. Thus, the matching area between the sidebar and the pin is increased, and the pins offer higher protection against heavy loads.
3. The integral heat treatment for the chain plates and rollers ensures high tensile strength. The pins additionally undergo high-frequency induction heating for the surface after integral heat treatment, ensuring high strength, high surface hardness, and wearing resistance as well. The surface carburizing treatment for the bushings or sleeves guarantees high tensile strength, superb surface hardness, and improved impact resistance. These make sure the heavy duty transmission chain has extended service life.


Technical Specifications

Chain No. includes: DC2814  DC4824  DC0635  DC1037   DC1245   WG781 ETC.


Chain No.
Pitch P (mm)Inner width of inner link plate b1 (max.) (mm)Diameter of roller d1 (max.) (mm)Height of sidebar h2 (max) (mm)Thickness of sidebar T (mm)Length of pin L (max.) (mm)Diameter of pin d2 (max.) (mm)Tensile strength Q (min.) (KN)Weight per meter q (kg)
DC281488.938.144.4563.514.2711823.81630
DC4824152.476.276.211525.4220421900
DC0635114.350.857.1576.214.2133.927.94760
DC6042C152.476.276.2101.619.0518638.11400
DC103778.13731.75438.79516.5294
DC1245103.4547.845.26014.212825.4550
DC153877.938.141.457.29.79719.05340
DC4014103.250.844.4557.212.7127.1422.1430
DC W140139.78665.29020190371200
DC3315103.4549.345.26014.213225.4550
DC6065C152.476.275.92120.6519.0518444.42268
DC103.2103.249.2466013123.223539
DC1031C78.136.833238.1888.215.77109
DC10199101.658.757.1576.212.713327.94850
DC13P78.138.131.75409.79516.5250
DC WTG8080383645109719.05288
DC4123-A103.8949.2150.869.8514.2912925.4694
DC88266.2728.5822.2328.46.467.511.1115.6
DC350088.938.644.455812.7113.3922.1559
DC503112769.963.588.915.88158.263.551332.8
DC6042152.474.676.21002018238.11600
DC1244103.24844.455513123.522476
DC WG103.2H103.249.2466016137.524622.3
DC RO3 1/288.936.931.756013.5117.622.23556
DC RO3C78.136.931.75459.595.316.5298.2
201063.538.131.7547.87.990.715.926214
251078.131.7536.940894.81627110.7
251277.939.641.28579.7103.419.0837818
281488.938.144.460.512.7117.622.2551625
3315103.4549.345.2463.514.2134.623.8559627
3618114.352.357.1579.214.2141.227.9781438
402012769.963.591.915.7168.131.78105452
4824152.476.276.2104.619187.538.13152168
WG/WB series
WG78178.1838.13345109717313.616
WG103103.249.2466013125.52353926
WG1401408065902018735117659.2
WB952595.25394565161242363522.2
WB7900793931.5549.593.518.538112.8
WB793879.3841.24057.29.510019.550918.7
WB23888.936.844.457.212.7113.422.15501.425.4
WB120712768.363.588.915.7158.331.75104453.1

Offset Sidebar Forged Chain Quality System Certification

Offset Sidebar Forged Chain ISO9001


Offset Sidebar Forged Chain Detail picture

Offset Sidebar Forged Chain


Heavy Duty Offset Sidebar Forged Chain Outer packaging

Heavy Duty Offset Sidebar Forged Chain ISO9001

Heavy Duty Offset Sidebar Forged Chain Quality System Certification

Heavy Duty Offset Sidebar Forged Chain with SGS Approved
