Wide Series Welded Steel Chain
Wide Series Welded Steel Chain
- Model: Wide Series Welded Steel Chain
wk1358@dongchuan.cn
Introduction
Wide Series Welded Steel Chain
Our wide series welded steel chain comes with narrow-end inner width options from 107.1mm to 326.1mm. For those products with higher requirement on corrosion resistance and tensile strength, we will conduct high frequency induction heating treatments to the pins and link plates, and can also manufacture the welded offset sidebar chains using stainless steel to enhance anti-corrosion performance. On this page, we show you wide series welded steel chain with sidebar thickness options from 9.5mm to 12.7mm, and tensile strength options from 170KN to 360KN.
|
| Chain no. | Pitch P (mm) | Sizes of bushing (max.) mm | Diameter of pin d2 (max.) (mm) | Height of sidebar h2 (max.) (mm) | Inner width of narrow end b1 (max.) (mm) | Outer width of narrow end b2 (max.) (mm) | Thickness of sidebar T (max.) (mm) | Tensile strength Q (min.) (KN) | Weight per meter q (kg/m) |
| 152.4 | D | 18.9 | 38.1 | 231.5 | 263.5 | 9.5 | 220 | 16.9 | |
| 152.4 | D | 18.9 | 38.1 | 231.5 | 263.5 | 9.5 | 170 | 16.9 | |
| 203.2 | D | 18.9 | 38.1 | 231.5 | 263.5 | 9.5 | 220 | 14.1 | |
| 203.2 | D | 18.9 | 38.1 | 231.5 | 263.5 | 9.5 | 170 | 14.1 | |
| 152.4 | A | 22.07 | 50.8 | 222.5 | 260.35 | 12.7 | 360 | 29 | |
| 152.4 | A | 22.07 | 50.8 | 222.5 | 260.35 | 12.7 | 310 | 29 | |
| 203.2 | A | 22.07 | 50.8 | 285.75 | 323.85 | 12.7 | 360 | 27 | |
| 203.2 | A | 22.07 | 50.8 | 285.75 | 323.85 | 12.7 | 310 | 27 | |
| 203.2 | E | 25.4 | 50.8 | 285.75 | 323.85 | 12.7 | 360 | 26.6 | |
| 203.2 | E | 25.4 | 50.8 | 285.75 | 323.85 | 12.7 | 310 | 26.6 | |
| 152.4 | D | 18.9 | 38.1 | 107.1 | 136.5 | 9.5 | 220 | 15.1 | |
| 152.4 | D | 18.9 | 38.1 | 107.1 | 136.5 | 9.5 | 170 | 15.1 | |
| 152.4 | C | 22.07 | 38.1 | 228.6 | 269.88 | 12.7 | 203 | 16.6 | |
| 152.4 | C | 22.07 | 38.1 | 228.6 | 269.88 | 12.7 | 165 | 16.6 | |
| 203.2 | B | 22.07 | 44.45 | 326.1 | 358.8 | 9.5 | 245 | 17.8 | |
| 203.2 | B | 22.07 | 44.45 | 326.1 | 358.8 | 9.5 | 203 | 17.8 |
Note: For details about bushing size, please contact us directly.
|
| Chain no. | Pitch P (mm) | Sizes of bushing (max.) (mm) | Diameter of pin d2 (max.) (mm) | Height of sidebar h2 (max.) (mm) | Inner width of narrow end b1 (max.) (mm) | Outer width of narrow end b2 (max.) (mm) | Thickness of sidebar T (max.) (mm) | Tensile strength Q (min.) (KN) | Weight per meter q (kg/m) |
| 155.85 | D | 18.9 | 38.1 | 236.5 | 263.5 | 9.5 | 220 | 16.9 | |
| 155.85 | D | 18.9 | 38.1 | 236.5 | 263.5 | 9.5 | 170 | 16.9 | |
| 207.29 | A | 22.07 | 50.8 | 285.75 | 323.85 | 12.7 | 360 | 26.7 | |
| 207.29 | A | 22.07 | 50.8 | 285.75 | 323.85 | 12.7 | 310 | 26.7 | |
| 203.2 | A | 22.07 | 50.8 | 285.75 | 323.85 | 12.7 | 360 | 27 | |
| 203.2 | A | 22.07 | 50.8 | 285.75 | 323.85 | 12.7 | 310 | 27 |
Note: For details about bushing size, please contact us directly.
