Wide Series Offset Sidebar Welded Conveyor Transmission Chain
    • Wide Series Offset Sidebar Welded Conveyor Transmission Chain
  • Wide Series Offset Sidebar Welded Conveyor Transmission Chain
  • Model: WDH110
  • Email  wk1358@dongchuan.cn
  • inquiry
Introduction

Wide Serise Welded Steel Chain And Attachments

Material :carbon steel
heat treatment :all parts heat treatment
surface:shot peening and oiling before packing,free of rust
quality inspection:check 20links for length precision,test hardness, pre-stretching after assembling,
package:polybag+plywood case

We can also design and produce products according to your design draws and specifications. Hence, if you need any special type of product, please contact us directly.

specification

chain no.pitch P (mm)diameter of bushing d1    (mm)diameter of pin  d2   (mm)height of sideba h2 (mm)inner width of close end b1 (mm)outer width of close end b2 (mm)thicknes of sidebar T (mm)tensile strength Q(KN)
WDH110152.4D18.938.1231.5263.59.5220
WDR110152.4D18.938.1231.5263.59.5170
WDH112203.2D18.938.1231.5263.59.5220
WDR112203.2D18.938.1231.5263.59.5170
WDH120152.4A22.0750.8222.526.3512.7360
WDR120152.4A22.0750.8222.526.3512.7310
WDH480203.2A22.0750.8285.75323.8512.7360
WDR480203.2A22.0750.8285.75323.8512.7360
WDH580203.2E25.450.8285.75323.8512.7360
WDR580203.2E25.450.8285.75323.8512.7310


If you need more information about this chain,please send email to us any time ,

Chain professional manufacturer


Chain Type
Welded chain,                    Roller chain,
Hollow pin chain ,               Drawbench chain,
Leaf chain,                         Engineering chain,
Paver chain,                       Bucket elevator chain,
Skid chain,                         Sugar mill chain,
Double flex chain,              Sharp top chain,
Forged chain,                   Cast chain ,
FV/FVC/FVT series chain,
M/MVT/MC serise chain,
Z/ZC serise chain,
stainless steel chain ,
Sprocket
Materialcarbon steel or Alloy with heat treatment /stainless steel                                                                                               (through harden/case  harden/induction harden)
Surfaceshot peening                                                                             zinc-plated
Dacromet                           blacking
lubricating ,free of rust
Quality inspectioninspect length precision and hardness,
pre-stretching after assembling,
Packagepolybag+plywood case
Applicationsugar mill,cement mil,l metallurgy industry,              automobile industry,grain machine.mining machine  and so on

steel welded chain

welded steel mill chain

steel welded chain ISO9001

steel welded chain Quality Management System Certification
